help with vacuum hoses

Discussion in '1965-1970 Shelby Mustang GT350 & GT500' started by lucky 31, Jan 12, 2014.

  1. lucky 31

    lucky 31 Member

    Posts:
    7
    Likes Received:
    0
    Joined:
    Jul 24, 2011
    Location:
    north carolina
    restoring 70 gt500 anyone know a website or can give any help on hooking up the vacuum hoses on engine thanks 31

  2. mrmustang

    mrmustang Well-Known Member

    Posts:
    507
    Likes Received:
    15
    Joined:
    Dec 23, 2004
    Location:
    Greenville, SC
    The SAACforum can help.

    Also, when you post, you should let them know whether you have AC, tilt wheel, emissions, how many ports are on your vacuum "block" etc.

    Pictures will help as well as the last four of your VIN (for running changes).


    Bill S.

  3. Coralsnake

    Coralsnake Well-Known Member

    Age:
    55
    Posts:
    1,048
    Likes Received:
    16
    Joined:
    Sep 8, 2004
    Location:
    The Northcoast
    Which transmission?

  4. lucky 31

    lucky 31 Member

    Posts:
    7
    Likes Received:
    0
    Joined:
    Jul 24, 2011
    Location:
    north carolina
    thanks for the response vin# 3142, 4 speed manual,no air condition , try to get a picture on tomorrow

  5. Coralsnake

    Coralsnake Well-Known Member

    Age:
    55
    Posts:
    1,048
    Likes Received:
    16
    Joined:
    Sep 8, 2004
    Location:
    The Northcoast
    On a 4spd you should have a dual vacuum advance and a three way vacuum tree on the thermostat housing. From memory...

    The yellow striped line goes from the top of the vacuum tree to the carb

    The green striped line goes from the middle vacuum tree port to the front of the advance

    The red striped line goes from the back of the vacuum advance to the bottom of the tree, it also has a t that goes to the front intake manifold fitting.

    The black hose goes from the anti backfire can of the smog to the rear intake fitting.

  6. lucky 31

    lucky 31 Member

    Posts:
    7
    Likes Received:
    0
    Joined:
    Jul 24, 2011
    Location:
    north carolina
    thanks for the help. Hope to get it fired up soon.
